Bespoke Hydraulic Solutions: Customizable P40-G12-G38-3OT Directional Control Valves

Kontrol Yöntemi:Manuel

Makara:3 Makara

Anma Akışı:40 L/dk (10,5 ABD galon/dak)

Maksimum Basınç:250 bar (3600 psi)

Giriş Portu:G1/2

Çıkış Portu:G1/2

Port Boyutu:G3/8

Marka:BXHS

Ürün Tipi:Monoblok Yönlendirmeli Vana

Ürün Serisi:P40 Serisi Monoblok Yönlendirmeli Vana

Ambalaj boyutu:24*21*13

Brüt ağırlık:7.00 kg

Stok Durumu: Stokta Var

967 Görünümler Bu Ürünü Arıyor

Bespoke Hydraulic Solutions: Customizable P40-G12-G38-3OT Directional Control Valves

Bespoke Hydraulic Solutions: Customizable P40-G12-G38-3OT Directional Control Valves

Bespoke Hydraulic Solutions: Customizable P40-G12-G38-3OT Directional Control Valves drawing image

Introducing our premium Bespoke Hydraulic Solutions: Customizable P40-G12-G38-3OT Directional Control Valves. Engineered with precision, these valves offer exceptional control and versatility for demanding hydraulic applications. With a rated flow of 40 L/min (10.5 US gpm) and a max pressure of 250 bar (3600 psi), they ensure reliable performance in diverse industries.

P40 Serisi Monoblok Yönlendirmeli Vana Parametreler
Kontrol Yöntemi Manuel, Pnömatik, Elektropnömatik, Elektrohidrolik, Selenoid, Hidrolik, Hidrolik ve Manuel, Kablo, Joystick, Solenoid ve Joystick, Manuel ve Joystick, Selenoid ve Kablo
Makara 1 Makara, 2 Makara, 3 Makara, 4 Makara, 5 Makara, 6 Makara, 7 Makara
Ortam Sıcaklık Aralığı -40°C ila +80°C (-40°F ila +176°F)
Yapı Türü Monoblock vana
Bölüm 1 Bölüm, 2 Bölüm, 3 Bölüm, 4 Bölüm, 5 Bölüm, 6 Bölüm, 7 Bölüm
İşletme Viskozite Aralığı 15 - 75 mm²/sn (15 cSt ila 75 cSt)
Anma Akışı 40 L/dk (10,5 ABD galon/dak)
Maksimum Basınç 250 bar (3600 psi)
Giriş Portu G3/8, G1/2, M18×1.5, M22×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT
Çıkış Portu G3/8, G1/2, M18×1.5, M22×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT
Port Boyutu G3/8, G1/2, M18×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT

Our customizable P40-G12-G38-3OT Directional Control Valves feature a robust monoblock valve structure, providing superior durability and leak-proof operation. They operate effortlessly with manual control, making them ideal for precise fluid management. The wide operating viscosity range of 15 - 75 mm²/s (15 cSt to 75 cSt) ensures compatibility with various hydraulic fluids. The valves are designed to withstand extreme temperatures from -40°C to +80°C (-40°F to +176°F), ensuring reliable operation in challenging environments.

We offer flexible manufacturing options, including OEM, private label, and custom design services. Our team of experts collaborates closely with customers to develop tailored solutions that meet specific application requirements. Whether you're a distributor, wholesaler, or end-user, we provide comprehensive support throughout the entire process.
