Customizable Solenoid Directional Valve | Made to Your Specifications

Kontrol Yöntemi:Selenoid

Makara:9 Makara

Anma Akışı:60 L/dk (15,8 ABD galon/dak)

Maksimum Basınç:315 bar (4600 psi)

Giriş Portu:G1/2

Çıkış Portu:G1/2

Port Boyutu:G1/2

Marka:BXHS

Ürün Tipi:Kesitsel Yönsel Valf

Ürün Serisi:DCV58 Serisi Kesitsel Yönsel Valf

Ambalaj boyutu:55*28*17

Brüt ağırlık:33.00 kg

Stok Durumu: Stokta Var

1057 Görünümler Bu Ürünü Arıyor

Customizable Solenoid Directional Valve | Made to Your Specifications

Customizable Solenoid Directional Valve | Made to Your Specifications

Customizable Solenoid Directional Valve | Made to Your Specifications drawing image

This is a high-performance, customizable hydraulic motor valve designed for demanding industrial applications. It features a 9-section, solenoid-controlled design, high flow rate (60 L/min), and high pressure rating (350 bar). Ideal for material handling, construction, agriculture, and industrial vehicles.

DCV58 Serisi Kesitsel Yönsel Valf Parametreler
Kontrol Yöntemi Selenoid, Solenoid ve Manuel
Makara 1 Makara, 2 Makara, 3 Makara, 4 Makara, 5 Makara, 6 Makara, 7 Makara, 8 Makara, 9 Makara, 10 Makara, 11 Makara, 12 Makara
Ortam Sıcaklık Aralığı -40°C ila +80°C (-40°F ila +176°F)
Yapı Türü Seksiyonel vana
Bölüm 1 Bölüm, 2 Bölüm, 3 Bölüm, 4 Bölüm, 5 Bölüm, 6 Bölüm, 7 Bölüm, 8 Bölüm, 9 Bölüm, 10 Bölüm, 11 Bölüm, 12 Bölüm
İşletme Viskozite Aralığı 15 - 75 mm²/sn (15 cSt ila 75 cSt)
Anma Akışı 40 L/dk (10,5 ABD galon/dak)
Maksimum Basınç 350 bar (5100 psi)
Giriş Portu G1/2, M22×1.5, SAE 10, 1/2 NPT
Çıkış Portu G1/2, M22×1.5, SAE 10, 1/2 NPT
Port Boyutu G1/2, M22×1.5, SAE 10, 1/2 NPT

This versatile **hydraulic motor valve** is a **customizable, high-performance** solution for your industrial needs. The **9-section, solenoid-controlled** design provides precise and reliable operation in a wide range of applications. With a **rated flow of 60 L/min** and a **maximum pressure of 350 bar**, this valve is capable of handling demanding workloads. The **sectional valve** construction allows for easy maintenance and repair. Designed for **heavy-duty operation**, it operates within a broad temperature range (-40°C to +80°C). Suitable for use in **material handling**, **construction and earth moving**, **agriculture**, and **industrial vehicles** such as **telehandlers**, **forklifts**, **all terrain cranes**, **stackers**, **aerial platforms**, **motor graders**, **midi-excavators**, **mini-excavators**, **skid steer loaders**, and **compact wheel loaders**. Part of the **DCV58 Series**, this valve is built to meet the highest industry standards.
