Exceptional Quality at Factory Prices: P40-2OT Hydraulic Directional Valves. Control Method: Manual and Joystick, Section: 2 Section, Structure Type: Monoblock valve, Rated Flow: 40 L/min (10.5 US gpm), Max Pressure: 250 bar (3600 psi), Operating Viscosity Range: 15 - 75 mm²/s (15 cSt to 75 cSt), Ambient Temperature Range: -40°C to +80°C (-40°F to +176°F), Spool: 2 Spool, Series: P40 Series, Application Area: MATERIAL HANDLING,CONSTRUCTION AND EARTH MOVING,AGRICULTURE,INDUSTRIAL VEHICLES, Applicable Model: TELEHANDLER,FORKLIFT,ALL TERRAIN CRANE,STACKER,AERIAL PLATFORM,MOTOR GRADER,MIDI-EXCAVATOR,MINI-EXCAVATOR,SKID STEER LOADER,COMPACT WHEEL LOADER
| P40 Serisi Monoblok Yönlendirmeli Vana Parametreler | |
|---|---|
| Kontrol Yöntemi | Manuel, Pnömatik, Elektropnömatik, Elektrohidrolik, Selenoid, Hidrolik, Hidrolik ve Manuel, Kablo, Joystick, Solenoid ve Joystick, Manuel ve Joystick, Selenoid ve Kablo |
| Makara | 1 Makara, 2 Makara, 3 Makara, 4 Makara, 5 Makara, 6 Makara, 7 Makara |
| Ortam Sıcaklık Aralığı | -40°C ila +80°C (-40°F ila +176°F) |
| Yapı Türü | Monoblock vana |
| Bölüm | 1 Bölüm, 2 Bölüm, 3 Bölüm, 4 Bölüm, 5 Bölüm, 6 Bölüm, 7 Bölüm |
| İşletme Viskozite Aralığı | 15 - 75 mm²/sn (15 cSt ila 75 cSt) |
| Anma Akışı | 40 L/dk (10,5 ABD galon/dak) |
| Maksimum Basınç | 250 bar (3600 psi) |
| Giriş Portu | G3/8, G1/2, M18×1.5, M22×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT |
| Çıkış Portu | G3/8, G1/2, M18×1.5, M22×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT |
| Port Boyutu | G3/8, G1/2, M18×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT |
The P40-2OT Hydraulic Directional Valves are manufactured by a leading hydraulic products manufacturer and are available at factory prices. These valves are designed for use in a wide range of applications, including material handling, construction and earth moving, agriculture, and industrial vehicles. The valves are available in manual and joystick control methods, and feature a monoblock valve structure, 40 L/min rated flow, 250 bar max pressure, and 2 spool. The valves are also suitable for use in a wide range of ambient temperatures, from -40°C to +80°C (-40°F to +176°F). If you are looking for high-quality hydraulic directional valves at factory prices, the P40-2OT series is an excellent option.
