Hydraulic Control Valve, 4-Spool, Manual Operation - P80-U78-4OT

Kontrol Yöntemi:Manuel

Makara:4 Makara

Anma Akışı:80 L/dk (21,2 ABD galon/dak)

Maksimum Basınç:250 bar (3600 psi)

Giriş Portu:SAE 10

Çıkış Portu:SAE 10

Port Boyutu:SAE 10

Marka:BXHS

Ürün Tipi:Monoblok Yönlendirmeli Vana

Ürün Serisi:P80 Serisi Monoblok Yönlendirmeli Vana

Ambalaj boyutu:26*27*11

Brüt ağırlık:13.40 kg

Stok Durumu: Stokta Var

1049 Görünümler Bu Ürünü Arıyor

Hydraulic Control Valve, 4-Spool, Manual Operation - P80-U78-4OT

Hydraulic Control Valve, 4-Spool, Manual Operation - P80-U78-4OT

Hydraulic Control Valve, 4-Spool, Manual Operation - P80-U78-4OT drawing image

The Hydro Control P80-U78-4OT is a 4-spool, manually operated hydraulic control valve designed for heavy-duty applications in material handling, construction, and agriculture. With a rated flow of 80 L/min and a maximum pressure of 250 bar, it is suitable for use in a wide range of industrial vehicles including telehandlers, forklifts, cranes, and excavators.

P80 Serisi Monoblok Yönlendirmeli Vana Parametreler
Kontrol Yöntemi Manuel, Pnömatik, Elektropnömatik, Elektrohidrolik, Selenoid, Hidrolik, Hidrolik ve Manuel, Kablo, Joystick, Manuel ve Joystick
Makara 1 Makara, 2 Makara, 3 Makara, 4 Makara, 5 Makara, 6 Makara, 7 Makara
Ortam Sıcaklık Aralığı -40°C ila +80°C (-40°F ila +176°F)
Yapı Türü Monoblock vana
Bölüm 1 Bölüm, 2 Bölüm, 3 Bölüm, 4 Bölüm, 5 Bölüm, 6 Bölüm, 7 Bölüm
İşletme Viskozite Aralığı 15 - 75 mm²/sn (15 cSt ila 75 cSt)
Anma Akışı 80 L/dk (21,2 ABD galon/dak)
Maksimum Basınç 315 bar (4600 psi)
Giriş Portu G1/2, G3/4, M27×2.0, SAE 10, SAE 12, 1/2 NPT, 3/4 NPT
Çıkış Portu G1/2, G3/4, M27×2.0, SAE 10, SAE 12, 1/2 NPT, 3/4 NPT
Port Boyutu G1/2, G3/4, M22×1.5, M27×2.0, SAE 10, 1/2 NPT, 3/4 NPT

The Hydro Control P80-U78-4OT is a robust and reliable hydraulic control valve designed for demanding applications. Its 4-spool, monoblock construction provides a compact and efficient design, while its manual operation allows for precise control of hydraulic functions. The valve is rated for a flow of 80 L/min and a maximum pressure of 250 bar, making it suitable for use in a wide range of industrial vehicles, including telehandlers, forklifts, cranes, stackers, aerial platforms, motor graders, mini-excavators, skid steer loaders, compact wheel loaders, and wheel loaders. The valve's operating viscosity range of 15 - 75 mm²/s (15 cSt to 75 cSt) ensures optimal performance in various operating conditions. It can withstand ambient temperatures ranging from -40°C to +80°C (-40°F to +176°F), making it suitable for use in a variety of climates. The P80-U78-4OT is a reliable and durable solution for controlling hydraulic systems in a variety of demanding applications.
