Hydraulic Directional Valve Customization | P80-G12-1OW Series

Kontrol Yöntemi:Manuel

Makara:1 Makara

Anma Akışı:80 L/dk (21,2 ABD galon/dak)

Maksimum Basınç:250 bar (3600 psi)

Giriş Portu:G1/2

Çıkış Portu:G1/2

Port Boyutu:G1/2

Marka:BXHS

Ürün Tipi:Monoblok Yönlendirmeli Vana

Ürün Serisi:P80 Serisi Monoblok Yönlendirmeli Vana

Ambalaj boyutu:26*15*11

Brüt ağırlık:5.00 kg

Stok Durumu: Stokta Var

1150 Görünümler Bu Ürünü Arıyor

Hydraulic Directional Valve Customization | P80-G12-1OW Series

Hydraulic Directional Valve Customization | P80-G12-1OW Series

Hydraulic Directional Valve Customization | P80-G12-1OW Series drawing image

The P80-G12-1OW Series hydraulic directional valve is a high-performance, manually controlled valve designed for use in a variety of material handling, construction, and industrial applications. It features a compact, monoblock design and is rated for 80 L/min (21.2 US gpm) flow at 250 bar (3600 psi). This valve is suitable for use in telehandlers, forklifts, all-terrain cranes, stackers, aerial platforms, motor graders, midi- excavators, mini- excavators, skid steer loaders, and compact wheel loaders.

P80 Serisi Monoblok Yönlendirmeli Vana Parametreler
Kontrol Yöntemi Manuel, Pnömatik, Elektropnömatik, Elektrohidrolik, Selenoid, Hidrolik, Hidrolik ve Manuel, Kablo, Joystick, Manuel ve Joystick
Makara 1 Makara, 2 Makara, 3 Makara, 4 Makara, 5 Makara, 6 Makara, 7 Makara
Ortam Sıcaklık Aralığı -40°C ila +80°C (-40°F ila +176°F)
Yapı Türü Monoblock vana
Bölüm 1 Bölüm, 2 Bölüm, 3 Bölüm, 4 Bölüm, 5 Bölüm, 6 Bölüm, 7 Bölüm
İşletme Viskozite Aralığı 15 - 75 mm²/sn (15 cSt ila 75 cSt)
Anma Akışı 80 L/dk (21,2 ABD galon/dak)
Maksimum Basınç 315 bar (4600 psi)
Giriş Portu G1/2, G3/4, M27×2.0, SAE 10, SAE 12, 1/2 NPT, 3/4 NPT
Çıkış Portu G1/2, G3/4, M27×2.0, SAE 10, SAE 12, 1/2 NPT, 3/4 NPT
Port Boyutu G1/2, G3/4, M22×1.5, M27×2.0, SAE 10, 1/2 NPT, 3/4 NPT

This P80 Series hydraulic directional valve is a manually controlled, monoblock valve offering high performance and durability. With a rated flow of 80 L/min (21.2 US gpm) and a maximum pressure of 250 bar (3600 psi), it's suitable for demanding applications across various industries. Its operating viscosity range is 15-75 mm²/s (15 cSt to 75 cSt), and it can withstand temperatures ranging from -40°C to +80°C (-40°F to +176°F). This versatile valve is ideal for applications in material handling, construction, and industrial vehicles, including telehandlers, forklifts, all-terrain cranes, stackers, aerial platforms, motor graders, midi-excavators, mini-excavators, skid steer loaders, and compact wheel loaders. Customization options are available to meet your specific needs.
