Üretim ve Teslimat
15-30 Gün Üretim Teslim Süresi



The P120-G1 Monoblock Directional Valve is a compact and robust hydraulic cylinder control unit designed for use in a wide range of applications including material handling, construction, and agriculture. It features a 120 L/min flow rate, 250 bar pressure rating, and a manual control method. This unit is perfect for applications requiring precise and reliable hydraulic control.
| P120 Serisi Monoblok Yönlendirmeli Vana Parametreler | |
|---|---|
| Kontrol Yöntemi | Manuel, Kablo, Joystick, Manuel ve Joystick |
| Makara | 1 Makara, 2 Makara, 3 Makara, 4 Makara |
| Anma Akışı | 120 L/dak (31.7 US gpm) |
| Maksimum Basınç | 250 bar (3600 psi) |
| Giriş Portu | G3/4, G1, M27×2.0, SAE 14, SAE 16, 3/4 NPT, 1 NPT, M36×2 |
| Çıkış Portu | G1, SAE 16, 1 NPT, M36×2 |
| Port Boyutu | G3/4, G1, M27×2.0, SAE 14, SAE 16, 1 NPT, M36×2 |
| Bölüm | 1 Bölüm, 2 Bölüm, 3 Bölüm, 4 Bölüm |
| Yapı Türü | Monoblock vana |
| Ortam Sıcaklık Aralığı | -40°C ila +80°C (-40°F ila +176°F) |
| İşletme Viskozite Aralığı | 15 - 75 mm²/sn (15 cSt ila 75 cSt) |
The P120-G1 Monoblock Directional Valve is a high-performance hydraulic cylinder control unit that offers exceptional reliability and durability. Designed for use in demanding environments, it features a robust monoblock valve construction and a 120 L/min flow rate, making it ideal for a wide range of applications. Its 250 bar pressure rating ensures it can handle heavy loads and demanding operating conditions. The manual control method provides precise and easy operation, while its compact design allows for easy integration into various systems. This unit is particularly well-suited for use in telehandlers, forklifts, all terrain cranes, stackers, aerial platforms, motor graders, midi-excavators, mini-excavators, skid steer loaders, and compact wheel loaders. Its wide operating temperature range (-40°C to +80°C) ensures it can perform reliably in a variety of climates.
