P40-G12-2OT Hydraulic Valve System | Performance & Reliability

Kontrol Yöntemi:Manuel

Makara:2 Makara

Anma Akışı:40 L/dk (10,5 ABD galon/dak)

Maksimum Basınç:250 bar (3600 psi)

Giriş Portu:G1/2

Çıkış Portu:G1/2

Port Boyutu:G1/2

Marka:BXHS

Ürün Tipi:Monoblok Yönlendirmeli Vana

Ürün Serisi:P40 Serisi Monoblok Yönlendirmeli Vana

Ambalaj boyutu:23*18*13

Brüt ağırlık:5.00 kg

Stok Durumu: Stokta Var

1176 Görünümler Bu Ürünü Arıyor

P40-G12-2OT Hydraulic Valve System | Performance & Reliability

P40-G12-2OT Hydraulic Valve System | Performance & Reliability

P40-G12-2OT Hydraulic Valve System | Performance & Reliability drawing image

The P40-G12-2OT is a high-performance, reliable hydraulic pressure control valve designed for a wide range of applications, including construction, material handling, agriculture, and industrial vehicles. This 2-section, monoblock valve features a manual control method, rated flow of 40 L/min, and a maximum pressure of 250 bar.

P40 Serisi Monoblok Yönlendirmeli Vana Parametreler
Kontrol Yöntemi Manuel, Pnömatik, Elektropnömatik, Elektrohidrolik, Selenoid, Hidrolik, Hidrolik ve Manuel, Kablo, Joystick, Solenoid ve Joystick, Manuel ve Joystick, Selenoid ve Kablo
Makara 1 Makara, 2 Makara, 3 Makara, 4 Makara, 5 Makara, 6 Makara, 7 Makara
Ortam Sıcaklık Aralığı -40°C ila +80°C (-40°F ila +176°F)
Yapı Türü Monoblock vana
Bölüm 1 Bölüm, 2 Bölüm, 3 Bölüm, 4 Bölüm, 5 Bölüm, 6 Bölüm, 7 Bölüm
İşletme Viskozite Aralığı 15 - 75 mm²/sn (15 cSt ila 75 cSt)
Anma Akışı 40 L/dk (10,5 ABD galon/dak)
Maksimum Basınç 250 bar (3600 psi)
Giriş Portu G3/8, G1/2, M18×1.5, M22×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT
Çıkış Portu G3/8, G1/2, M18×1.5, M22×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT
Port Boyutu G3/8, G1/2, M18×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT

The P40-G12-2OT hydraulic pressure control valve is a robust and efficient solution for various mobile equipment. It offers a compact design with a 2-spool configuration, providing precise control over hydraulic systems. This monoblock valve is built for durability and reliability, operating within a wide viscosity range and temperature range. Its manual control method allows for simple and intuitive operation. With a rated flow of 40 L/min and a maximum pressure of 250 bar, this valve is suitable for a wide range of applications in construction, material handling, agriculture, and industrial vehicles. Some examples of its applications include telehandlers, forklifts, all-terrain cranes, stackers, aerial platforms, motor graders, midi-excavators, mini-excavators, skid steer loaders, and compact wheel loaders.
