P40-U34 Directional Valve | High-Pressure & Long Service Life

Kontrol Yöntemi:Manuel

Makara:1 Makara

Anma Akışı:40 L/dk (10,5 ABD galon/dak)

Maksimum Basınç:250 bar (3600 psi)

Giriş Portu:SAE 8

Çıkış Portu:SAE 8

Port Boyutu:SAE 8

Marka:BXHS

Ürün Tipi:Monoblok Yönlendirmeli Vana

Ürün Serisi:P40 Serisi Monoblok Yönlendirmeli Vana

Ambalaj boyutu:23*16*11

Brüt ağırlık:3.00 kg

Stok Durumu: Stokta Var

1080 Görünümler Bu Ürünü Arıyor

P40-U34 Directional Valve | High-Pressure & Long Service Life

P40-U34 Directional Valve | High-Pressure & Long Service Life

P40-U34 Directional Valve | High-Pressure & Long Service Life drawing image

This P40 Series hydraulic solenoid valve is a high-performance directional control valve designed for demanding applications in construction, material handling, agriculture, and industrial vehicles. It features a 220 Volt operation, high pressure rating, long service life, and a compact monoblock structure.

P40 Serisi Monoblok Yönlendirmeli Vana Parametreler
Kontrol Yöntemi Manuel, Pnömatik, Elektropnömatik, Elektrohidrolik, Selenoid, Hidrolik, Hidrolik ve Manuel, Kablo, Joystick, Solenoid ve Joystick, Manuel ve Joystick, Selenoid ve Kablo
Makara 1 Makara, 2 Makara, 3 Makara, 4 Makara, 5 Makara, 6 Makara, 7 Makara
Ortam Sıcaklık Aralığı -40°C ila +80°C (-40°F ila +176°F)
Yapı Türü Monoblock vana
Bölüm 1 Bölüm, 2 Bölüm, 3 Bölüm, 4 Bölüm, 5 Bölüm, 6 Bölüm, 7 Bölüm
İşletme Viskozite Aralığı 15 - 75 mm²/sn (15 cSt ila 75 cSt)
Anma Akışı 40 L/dk (10,5 ABD galon/dak)
Maksimum Basınç 250 bar (3600 psi)
Giriş Portu G3/8, G1/2, M18×1.5, M22×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT
Çıkış Portu G3/8, G1/2, M18×1.5, M22×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT
Port Boyutu G3/8, G1/2, M18×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT

The P40-U34 directional valve is a robust and reliable hydraulic solenoid valve built for heavy-duty applications. This 220 Volt valve provides precise control of hydraulic fluid flow with a maximum pressure rating of 250 bar (3600 psi). The valve boasts a long service life, thanks to its durable construction and high-quality materials. Designed as a monoblock valve, the P40-U34 offers a compact and efficient solution for a wide range of applications. It is perfect for use in telehandlers, forklifts, cranes, stackers, aerial platforms, motor graders, midi-excavators, mini-excavators, and skid steer loaders. The valve's operating viscosity range of 15-75 mm²/s (15 cSt to 75 cSt) and ambient temperature range of -40°C to +80°C (-40°F to +176°F) ensure reliable operation in a variety of harsh environments.
