P40-XNHJ Monoblock Directional Valve: Wholesale Prices from the Factory

Kontrol Yöntemi:Manuel

Makara:2 Makara

Anma Akışı:40 L/dk (10,5 ABD galon/dak)

Maksimum Basınç:250 bar (3600 psi)

Giriş Portu:G1/2

Çıkış Portu:G1/2

Port Boyutu:G3/8

Marka:BXHS

Ürün Tipi:Monoblok Yönlendirmeli Vana

Ürün Serisi:P40-XNHJ Serisi Monoblok Yönlendirmeli Vana

Ambalaj boyutu:23*18*11

Brüt ağırlık:5.00 kg

Stok Durumu: Stokta Var

511 Görünümler Bu Ürünü Arıyor

P40-XNHJ Monoblock Directional Valve: Wholesale Prices from the Factory

P40-XNHJ Monoblock Directional Valve: Wholesale Prices from the Factory

P40-XNHJ Monoblock Directional Valve: Wholesale Prices from the Factory drawing image

High-quality P40-XNHJ series monoblock directional hydraulic valves, offering 40 L/min flow rate and 250 bar max pressure. Ideal for material handling, construction, agriculture, and industrial vehicles. Factory direct wholesale prices available.

P40-XNHJ Serisi Monoblok Yönlendirmeli Vana Parametreler
Kontrol Yöntemi Manuel, Pnömatik, Elektropnömatik, Elektrohidrolik, Selenoid, Hidrolik, Hidrolik ve Manuel, Kablo, Joystick, Manuel ve Joystick
Makara 1 Makara, 2 Makara, 3 Makara, 4 Makara, 5 Makara, 6 Makara, 7 Makara
Anma Akışı 40 L/dk (10,5 ABD galon/dak)
Maksimum Basınç 250 bar (3600 psi)
Giriş Portu G3/8, G1/2, M18×1.5, M22×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT
Çıkış Portu G3/8, G1/2, M18×1.5, M22×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT
Port Boyutu G3/8, G1/2, M18×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT
Bölüm 1 Bölüm, 2 Bölüm, 3 Bölüm, 4 Bölüm, 5 Bölüm, 6 Bölüm, 7 Bölüm
Yapı Türü Monoblock vana
Ortam Sıcaklık Aralığı -40°C ila +80°C (-40°F ila +176°F)
İşletme Viskozite Aralığı 15 - 75 mm²/sn (15 cSt ila 75 cSt)

The P40-XNHJ Monoblock Directional Valve is a robust and reliable hydraulic control solution, perfect for a wide range of applications. This 2-section, manual control valve boasts a rated flow of 40 L/min (10.5 US gpm) and a maximum pressure of 250 bar (3600 psi). Its operating viscosity range is 15-75 mm²/s (15 cSt to 75 cSt), and it's designed to withstand ambient temperatures from -40°C to +80°C (-40°F to +176°F). Featuring a 2-spool design, this valve is ideal for various equipment including forklifts, telehandlers, skid steer loaders, tractors, mini-excavators, backhoes, balers, harvesters, and sprayers.

As a leading **manufacturer** and factory supplier of hydraulic valves, we offer **wholesale** prices directly from our factory. We also provide **OEM**, **private labeling** and **customization** services to meet your specific needs. We are actively seeking reliable **distributors**, **wholesalers**, **agents**, and **trading companies** globally to partner with us and expand our market reach. Contact us today to discuss your requirements and explore mutually beneficial collaborations. We offer competitive pricing and excellent quality for all your **hydraulic valve** needs. Choose our **factory direct** supply for superior value and guaranteed satisfaction. Our **P40 valve** is a high-performance solution you can trust.
