Üretim ve Teslimat
15-30 Gün Üretim Teslim Süresi



This 12V Hydraulic Spool Valve offers reliable control for various applications in material handling, construction, agriculture, and industrial vehicles. It features manual control, 2 sections, and a monoblock design. With a flow rate of 40 L/min and a maximum pressure of 250 bar, it provides robust performance. We offer OEM, private label, and customized solutions to meet your specific needs.
| P40 Serisi Monoblok Yönlendirmeli Vana Parametreler | |
|---|---|
| Kontrol Yöntemi | Manuel, Pnömatik, Elektropnömatik, Elektrohidrolik, Selenoid, Hidrolik, Hidrolik ve Manuel, Kablo, Joystick, Solenoid ve Joystick, Manuel ve Joystick, Selenoid ve Kablo |
| Makara | 1 Makara, 2 Makara, 3 Makara, 4 Makara, 5 Makara, 6 Makara, 7 Makara |
| Ortam Sıcaklık Aralığı | -40°C ila +80°C (-40°F ila +176°F) |
| Yapı Türü | Monoblock vana |
| Bölüm | 1 Bölüm, 2 Bölüm, 3 Bölüm, 4 Bölüm, 5 Bölüm, 6 Bölüm, 7 Bölüm |
| İşletme Viskozite Aralığı | 15 - 75 mm²/sn (15 cSt ila 75 cSt) |
| Anma Akışı | 40 L/dk (10,5 ABD galon/dak) |
| Maksimum Basınç | 250 bar (3600 psi) |
| Giriş Portu | G3/8, G1/2, M18×1.5, M22×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT |
| Çıkış Portu | G3/8, G1/2, M18×1.5, M22×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT |
| Port Boyutu | G3/8, G1/2, M18×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT |
This 12V Hydraulic Spool Valve is a high-performance, reliable control solution for a wide range of applications in industries such as material handling, construction, agriculture, and industrial vehicles. Featuring manual control, 2 sections, and a monoblock design, this valve provides precise and efficient operation. It boasts a flow rate of 40 L/min and a maximum pressure of 250 bar, ensuring robust performance in demanding environments. With an operating viscosity range of 15 - 75 mm²/s and an ambient temperature range of -40°C to +80°C, this valve is designed for diverse conditions. Our expertise in manufacturing, OEM, private label, and custom solutions allows us to tailor this product to your specific requirements. We are committed to delivering high-quality hydraulic valves that meet your exact specifications and contribute to your brand's success.
