Solenoid Hydraulic Valve | P40-DKL | Contact Us for Specifications

Kontrol Yöntemi:Selenoid

Makara:3 Makara

Anma Akışı:40 L/dk (10,5 ABD galon/dak)

Maksimum Basınç:250 bar (3600 psi)

Giriş Portu:G1/2

Çıkış Portu:G1/2

Port Boyutu:G3/8

Marka:BXHS

Ürün Tipi:Monoblok Yönlendirmeli Vana

Ürün Serisi:P40-DKL Serisi Monoblok Yönlendirmeli Vana

Ambalaj boyutu:31*21*17

Brüt ağırlık:9.00 kg

Stok Durumu: Stokta Var

1305 Görünümler Bu Ürünü Arıyor

Solenoid Hydraulic Valve | P40-DKL | Contact Us for Specifications

Solenoid Hydraulic Valve | P40-DKL | Contact Us for Specifications

Solenoid Hydraulic Valve | P40-DKL | Contact Us for Specifications drawing image

The P40-DKL series is a 3-section monoblock solenoid valve designed for heavy-duty applications in material handling, construction, and agriculture. With a rated flow of 40 L/min and a max pressure of 250 bar, this valve is ideal for controlling hydraulic actuators in a variety of equipment, including telehandlers, forklifts, and excavators.

P40-DKL Serisi Monoblok Yönlendirmeli Vana Parametreler
Kontrol Yöntemi Manuel, Pnömatik, Elektropnömatik, Elektrohidrolik, Selenoid, Hidrolik, Hidrolik ve Manuel, Kablo, Joystick, Manuel ve Joystick
Makara 1 Makara, 2 Makara, 3 Makara, 4 Makara, 5 Makara, 6 Makara, 7 Makara
Anma Akışı 40 L/dk (10,5 ABD galon/dak)
Maksimum Basınç 250 bar (3600 psi)
Giriş Portu G3/8, G1/2, M18×1.5, M22×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT
Çıkış Portu G3/8, G1/2, M18×1.5, M22×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT
Port Boyutu G3/8, G1/2, M18×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT
Bölüm 1 Bölüm, 2 Bölüm, 3 Bölüm, 4 Bölüm, 5 Bölüm, 6 Bölüm, 7 Bölüm
Yapı Türü Monoblock vana
Ortam Sıcaklık Aralığı -40°C ila +80°C (-40°F ila +176°F)
İşletme Viskozite Aralığı 15 - 75 mm²/sn (15 cSt ila 75 cSt)

This P40-DKL series tractor 3-point control valve features a solenoid actuation method for precise control of hydraulic functions. Its 3-section design provides separate control of multiple hydraulic circuits. The valve is constructed with a robust monoblock design, ensuring long-lasting durability in demanding applications. With a rated flow of 40 L/min and a max pressure of 250 bar, this valve is suitable for a wide range of equipment in industries such as material handling, construction, and agriculture. The P40-DKL series is compatible with a variety of equipment, including telehandlers, forklifts, all terrain cranes, stackers, aerial platforms, motor graders, midi-excavators, mini-excavators, skid steer loaders, and compact wheel loaders.
