Source Directly & Save: SD25 Valves from the Factory Producer

Kontrol Yöntemi:Manuel

Makara:1 Makara

Anma Akışı:240 L/dk (63,4 ABD galon/dak)

Maksimum Basınç:315 bar (4600 psi)

Giriş Portu:G1

Çıkış Portu:G1-1/4

Port Boyutu:G1

Marka:BXHS

Ürün Tipi:Kesitsel Yönsel Valf

Ürün Serisi:SD25 Serisi Kesitsel Yönsel Valf

Ambalaj boyutu:30*45*20

Brüt ağırlık:28.50 kg

Stok Durumu: Stokta Var

1163 Görünümler Bu Ürünü Arıyor

Source Directly & Save: SD25 Valves from the Factory Producer

Source Directly & Save: SD25 Valves from the Factory Producer

Source Directly & Save: SD25 Valves from the Factory Producer drawing image

Our SD25 series two spool hydraulic control valve is a high-performance, reliable option for various applications, including construction equipment, material handling, agriculture, and industrial vehicles. This manual control valve offers a rated flow of 240 L/min (63.4 US gpm) and a max pressure of 315 bar (4600 psi). Designed for durability and efficiency, it is suitable for demanding environments.

SD25 Serisi Kesitsel Yönsel Valf Parametreler
Kontrol Yöntemi Manuel, Elektrohidrolik, Hidrolik
Makara 1 Makara, 2 Makara, 3 Makara, 4 Makara, 5 Makara, 6 Makara
Ortam Sıcaklık Aralığı -40°C ila +80°C (-40°F ila +176°F)
Yapı Türü Seksiyonel vana
Bölüm 1 Bölüm, 2 Bölüm, 3 Bölüm, 4 Bölüm, 5 Bölüm, 6 Bölüm, 7 Bölüm, 8 Bölüm, 9 Bölüm, 10 Bölüm
İşletme Viskozite Aralığı 12 - 400 mm²/sn (12 cSt ila 400 cSt)
Anma Akışı 240 L/dk (63,4 ABD galon/dak)
Maksimum Basınç 315 bar (4600 psi)
Giriş Portu G1, SAE 16
Çıkış Portu G1-1/4, SAE 16
Port Boyutu G1, G1-1/4, SAE 12

The SD25 series two spool hydraulic control valve is a reliable and efficient solution for various applications. Manufactured directly from our factory, we offer wholesale pricing and direct supply, ensuring competitive pricing and high-quality products. This monoblock valve features manual control, a rated flow of 240 L/min (63.4 US gpm), and a maximum pressure of 315 bar (4600 psi). It operates within a viscosity range of 12 - 400 mm²/s (12 cSt to 400 cSt) and is suitable for ambient temperatures ranging from -40°C to +80°C (-40°F to +176°F). Designed for various applications in material handling, construction and earth moving, agriculture, and industrial vehicles, this valve is perfect for telehandlers, forklifts, all-terrain cranes, stackers, aerial platforms, motor graders, mini-excavators, skid steer loaders, compact wheel loaders, and wheel loaders. Choose our SD25 series two spool hydraulic control valve for reliable performance and cost-effectiveness, directly from the factory.
