Wholesale SD8 Manual 4 Spool Sectional Directional Valve from Factory

Kontrol Yöntemi:Manuel

Makara:4 Makara

Anma Akışı:90 L/dk (23,8 ABD galon/dak)

Maksimum Basınç:315 bar (4600 psi)

Giriş Portu:G1/2

Çıkış Portu:G3/4

Port Boyutu:G1/2

Marka:BXHS

Ürün Tipi:Kesitsel Yönsel Valf

Ürün Serisi:SD8 Serisi Kesitsel Yönsel Valf

Ambalaj boyutu:32*36*16

Brüt ağırlık:18.00 kg

Stok Durumu: Stokta Var

104 Görünümler Bu Ürünü Arıyor

Wholesale SD8 Manual 4 Spool Sectional Directional Valve from Factory

Wholesale SD8 Manual 4 Spool Sectional Directional Valve from Factory

Wholesale SD8 Manual 4 Spool Sectional Directional Valve from Factory drawing image

High-performance SD8 series 4-spool manual sectional directional valve, designed for 80 L/min flow and 315 bar pressure, ideal for demanding agricultural and construction machinery applications.

SD8 Serisi Kesitsel Yönsel Valf Parametreler
Kontrol Yöntemi Manuel, Pnömatik, Elektropnömatik, Elektrohidrolik, Selenoid, Hidrolik, Hidrolik ve Manuel, Kablo, Joystick, Solenoid ve Joystick, Manuel ve Joystick
Makara 1 Makara, 2 Makara, 3 Makara, 4 Makara, 5 Makara, 6 Makara, 7 Makara, 8 Makara, 9 Makara, 10 Makara
Ortam Sıcaklık Aralığı -40°C ila +80°C (-40°F ila +176°F)
Yapı Türü Seksiyonel vana
Bölüm 1 Bölüm, 2 Bölüm, 3 Bölüm, 4 Bölüm, 5 Bölüm, 6 Bölüm, 7 Bölüm, 8 Bölüm, 9 Bölüm, 10 Bölüm
İşletme Viskozite Aralığı 12 - 400 mm²/sn (12 cSt ila 400 cSt)
Anma Akışı 90 L/dk (23,8 ABD galon/dak)
Maksimum Basınç 315 bar (4600 psi)
Giriş Portu G1/2, G3/4, SAE 10
Çıkış Portu G1/2, G3/4, SAE 10, 3/4 NPT
Port Boyutu G1/2, SAE 10

As a prominent hydraulic manufacturer, we offer the SD8 series manual 4-spool sectional directional valve engineered for precision and durability. This versatile valve supports a rated flow of 80 L/min (21.2 US gpm) and a maximum pressure of 315 bar (4600 psi), featuring G1/2 inlet and G3/4 outlet ports. Our factory specializes in large-scale production, providing extensive opportunities for OEM, ODM, and private labeling (branding) to meet specific technical requirements. The SD8 series is widely applied in forklifts, skid steer loaders, mini-excavators, and wood splitters across the material handling and agricultural sectors. We are actively seeking global partners, including distributors, wholesalers, and international traders, to expand our market reach. Benefit from factory-direct wholesale pricing, reliable supply chains, and customizable hydraulic solutions. Our manufacturing excellence ensures consistent quality for heavy-duty industrial vehicles and specialized machinery manufacturers worldwide.
